Bluevolution 73

5 Chambers

Salamander profile with 5 insulation chambers.

73 mm

Construction depth.

1,25 – 1,5 mm reinforcement

Standard stiffening with closed galvanised steel on the heel.

2 gaskets

Profile system with 2 insulation gaskets.

Maco Multimatic Austria fittings

Equipped with economical ventilation.

Double and triple glazing

Double and triple insulating glass 28 and 40 mm, aluminium spacer strip.

Technical details

  • Salamander profile: 5 chambers, 2 seals, 100% made in Germany. Available only L frame or renovation frame with 35mm flange;
  • Construction depth: 73mm;
  • Glass package. Double glazing with 2 sheets of 24mm glass, aluminium spacer strip;
  • Class B. Uw = 0,86 – 1,3 W/mp2 K
  • Sash: straight;
  • Sound insulation: up to 46 dB
  • Stiffening: 1.25mm – 1.5mm;
  • Maco Multimatic Austria fittings. Equipped as standard with micro-ventilation, secustik handles, mechanism against incorrect operation.
