EvolutionDrive Plus

EvolutionDrive Plus sliding doors impress with their space-saving sliding and ventilation convenience, as well as their space-opening effect.

Sliding elements make the rooms feel more spacious and much brighter, and make the passage to the outside more accessible.

Panoramic, space-saving, easy to use = EvolutionDrive Plus

Technical details

  • Salamander EvolutionDrive Plus profile;
  • 152 mm construction depth with 2 reinforcement chambers for greater stability;
  • 76mm deep on the sash and 108mm high;
  • Possibility to add the clip profile to get the renovation frame;
  • Max. execution dimensions -4000 mm length * 2600 mm height;
  • Possibility of burying the heel 2 cm on the outside and max 2.5 cm on the inside.

MACO fittings

  • Safety class RC2;
  • Perimeter enclosure;
  • Execution schemes A SI C;
  • Possibility of double handle with key lock.

Glass

  • Possibility of 2 or 3 sheets of glass up to 48 mm thick;
  • Warm-edge spacer and Argon.
